JL002-61101 HP 5406R 8P SFP+(No Psu)/8P 10Gbase-T v3 zl2 Switch
JL002-61101 Overview
The HP JL002-61101 5406R v3 zl2 is a Layer 3 fully managed modular switch featuring 8 SFP+ ports and 8 10GBase-T ports, designed for enterprise core, aggregation, and high-performance data center networks. It provides high-speed connectivity, low-latency switching, and scalability for demanding environments.As part of the zl2 series, the switch supports modular expansion, redundancy, and flexible deployment options. It offers advanced Layer 2 and Layer 3 features, including VLANs, link aggregation, dynamic routing, QoS, and enterprise-grade security with ACLs, RADIUS, and TACACS+, ensuring efficient traffic management, secure operations, and optimized performance.
JL002-61101 Technical Specifications
HP 5406R 8P SFP+(No Psu)/8P 10Gbase-T v3 zl2 Switch
Manufacturer Part Number: JL002-61101
Brand Name: HP
Product Line: HP 5406R v3 zl2 Series
Product Type: Layer 3 Managed Gigabit / 10 Gigabit Ethernet Switch
Total Ports: 16
Gigabit / 10GbE Ports: 8 x 10GBASE-T RJ-45, 8 x 10GbE SFP+
Uplink/Expansion Ports: Included in 8 SFP+ ports
Power Supply: Not Included (No PSU)
Layer Support: Layer 2 / Layer 3
Switching Capacity: 136 Gbps
Forwarding Rate: 101 Mpps
MAC Address Table: 32,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: IEEE 802.1D, 802.1w, 802.1s
Static Routing: IPv4 / IPv6 Supported
Dynamic Routing: OSPF, RIP, BGP Supported
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service: 8 Priority Queues, IEEE 802.1p, DiffServ
