N2K-C2248TR-E Technical Specifications
Cisco Nexus 10GE 48 Ports Fabric Extender
Manufacturer: Cisco Systems, Inc
Brand: Cisco
Product Line: Nexus
Product Series: 2000
Product Model: 2248TP-E
Product Name: Nexus 2248TP-E with 1 x QSFP-40G-SR4 and 4 x SFP-10G-SR
Product Type: Fabric Extender
Networking
Ports: Gigabit Ethernet x 48
Connectivity Technology: Wired
Cabling Type:Ethernet 100Base-TX, Ethernet 1000Base-T
Data Link Protocol: Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol: TCP/IP, UDP/IP, ICMP/IP
Expansion / Connectivity
Interfaces: 48 x 1000Base-T – RJ-45 4 x 10Gb Ethernet – SFP
Power
Power Device: Plug-in module
Voltage Required: AC 120/230 V (50/60 Hz)
Power Consumption Operational: 110 Watt
Dimensions & Weight
Width: 17.3 Inch
Depth: 17.7 Inch
Height: 1.7 Inch
Weight: 17.64 Lbs
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
