WSP-Q40GLR4L Cisco 40G Fabric Extender Transceiver QSFP+ Module
WSP-Q40GLR4L Overview
Cisco 40GBASE-LR4L QSFP+ Optical Transceiver Module (SMF, 1310nm, 2km, LC, DOM)
The QSFP+ module is designed for use in 40GBASE Ethernet throughput up to 2km over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. This transceiver is compliant with QSFP+ MSA and IEEE 802.3ba 40GBASE-LR4 standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP+ MSA, to allow access to real-time operating parameters.
$405
WSP-Q40GLR4L Technical Specifications
Cisco 40G Fabric Extender Transceiver QSFP+ Transceiver Module
General Information
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: 40GBase-LR4L QSFP Module for SMF
Product Type: QSFP
Cisco Transceiver
Technical Information
Application/Usage: Optical Network
Application/Usage: Data Networking
Interfaces/Ports
Interfaces/Ports Details: 1 x LC Duplex 40GBase-LR4 Network
Ethernet Technology: 40 Gigabit Ethernet
Media & Performance
Fiber Mode Supported Single-mode Fiber (SMF)
Maximum Data Transfer Rate: 40
Miscellaneous
Compatibility MSA Compliant
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
