Q2F24A HP 8 x Ports QSFP28 100GBase-X Switch
Q2F24A Overview
The HP Q2F24A is a high-performance 8-port 100 Gigabit Ethernet (100GbE) QSFP28 switch designed for enterprise data centers, high-speed aggregation, and cloud network infrastructures. It provides 8 QSFP28 ports, delivering ultra-fast, low-latency 100GbE connectivity for servers, storage, and uplinks, supporting bandwidth-intensive applications and large-scale virtualized environments.The switch supports advanced Layer 2 and Layer 3 functionality, including VLANs, link aggregation (LACP), QoS, and routing protocols such as static routing, OSPF, and BGP, allowing efficient and scalable network traffic management. Security is enhanced with ACLs and authentication mechanisms, ensuring secure and segmented network operations.
Q2F24A Technical Specifications
HP 8 x Ports QSFP28 100GBase-X Switch
Manufacturer Part Number: Q2F24A
Brand Name: HP
Product Type: Managed 100GbE Switch
Total Ports: 8
100-Gigabit Ethernet Ports: 8 x QSFP28
Uplink Ports: Not applicable (all ports QSFP28)
Switching Capacity: 1.6 Tbps
Forwarding Rate: 1,190 Mpps
Layer Support: Layer 2 / Layer 3 / Layer 4
MAC Address Table: 512,000 entries
VLAN Support: 4,094 VLANs (IEEE 802.1Q)
Routing: Static, RIP, OSPF, BGP, IPv4/IPv6
Spanning Tree Protocols: STP, RSTP, MSTP
Link Aggregation: IEEE 802.3ad LACP
Quality of Service (QoS): 8 queues, DSCP, IEEE 802.1p
Security: ACLs, 802.1X, DHCP Snooping, uRPF, DoS Protection
Management: CLI, Web UI, SNMP, RMON, sFlow
Port Mirroring: Supported
