QFX5130-32CD-D-AFO Juniper Networks 32X400G 1u DC Airflow Out
QFX5130-32CD-D-AFO Overview
The QFX5130 Switch offers a high-density, cost-optimized 1 U 400GbE fixed-configuration platform ideal for data centers where cloud services are being added. These services require higher network bandwidth per rack, as well as flexibility, making the 10/25/40/100/400GbE interface options ideal for server and intra-fabric connectivity. The QFX5130 is an optimal choice for spine-and-leaf deployments in enterprise, service provider, and cloud provider data centers. Coupled with the widespread adoption of overlay technologies, the QFX5130 lays a strong foundation for your evolving business and network needs, offering deployment versatility to future-proof your network investment.
$35,099
QFX5130-32CD-D-AFO Technical Specifications
Juniper Networks 32X400G 1u DC Airflow Out
Manufacturer Part Number: QFX5130-32CD-D-AFO
Product Type: Layer 3 Switch
Manageable: Yes
Ethernet Technology; 400 Gigabit Ethernet, 25 Gigabit Ethernet
Number of Total Expansion Slots: 34
Product Family: QFX5100
Media Type Supported: Optical Fiber
Total Number of Network Ports: 34
Redundant Power Supply Supported: Yes
TAA Compliant; Yes
Expansion Slot Type: QSFP56-DD, SFP+
Form Factor: Rack-mountable
Power Consumption: 973 W
Power Source: Power Supply
Layer Supported: 3
Environmentally Friendly: Yes
Compatible Rack Unit: 1U
Number of Power Supplies Supported; 2
Number of Power Supplies Installed: 2
Number of SFP+ Slots: 2
Modular: Yes
Uplink Port: Yes
Height: 1.7″
Width: 17.3″
Depth: 21.1″
Product Series: QFX5100
Product Model: QFX5130-32CD
Network Technology: 25GBase-X
