ROG STRIX X570-E ASUS Republic of Gamers Strix X570-E

ROG STRIX X570-E Technical Specifications

ASUS Republic of Gamers Strix X570-E

CPU
Chipset AMD X570
CPU Socket AM4
Back Panel I/O
USB 7 x USB 3.1 / USB 3.2 Gen 2 Type-A
1 x USB 3.1 / USB 3.2 Gen 2 Type-C
Thunderbolt None
Display 1 x DisplayPort 1.2
1 x HDMI 2.0
Audio 1 x S/PDIF
5 x 3.5 mm
Ethernet / Controller 1 x Realtek RTL8125-CG 2.5Gigabit
1 x Intel I211-AT Gigabit
Wi-Fi Antenna 2 x Connector
Buttons BIOS Flashback
Memory
Memory Slots 4 x 288-Pin
Memory Support DDR4 2133, 2400, 2666, 2800, 3000, 3200, 3400, 3600, 3866, 4000, 4133, 4266, 4400 MHz
Maximum Capacity 128 GB
Channel Architecture Dual Channel
ECC Support Non-ECC Unbuffered
Storage Expansion
SATA 8 x SATA III
M.2 2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, SATA III)
U.2 None
RAID Support RAID 0, 1, 10 (SATA)
Internal I/O
Expansion Slots 2 x PCIe 4.0 x16
1 x PCIe 4.0 x16 (x4 mode)
2 x PCIe 4.0 x1
USB 1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port)
1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)
2 x USB 2.0 Header (Supports 4 USB Type-A Port)
Multi-GPU Support 2-Way NVIDIA SLI
2-Way, 3-Way AMD CrossFireX
Air Cooling 1 x 4-Pin CPU
1 x 4-Pin Assistant
4 x 4-Pin System
2 x Thermal Sensor
Liquid Cooling 2 x 4-Pin Pump
Power Connectors 1 x 24-Pin Mainboard
1 x 8-Pin CPU
1 x 4-Pin CPU
Security TPM Module
LED Header 4 x RGB
Audio None
Diagnostics Clear CMOS
BIOS
ROM 256 Mb
Front Panel I/O
I/O Connection Headers AAFP, USB 3.1
Audio
Audio Codec SupremeFX S1220A (8-Channel)
Wireless
Bluetooth 5.0
Wi-Fi Wi-Fi 6 (802.11ax) (MU-MIMO)
Software
Supported Operating Systems Windows 10 (64-Bit)
Physical
Form Factor ATX
Dimensions 12 x 9.6″ / 304.80 x 243.84 mm
