SAS9500-16I Broadcom 16-Port Int 12Gb/s SAS/SATA/PCIE (NVMe) Tri-Mode HBA
SAS9500-16I Overview
The High-port 9500-16i Tri-mode, Pcie Gen 4.0 Hba Is Ideal For Increased Connectivity And Maximum Performance For Enterprise Data Center Flexibility
With Increased Bandwidth And Iops Performance Compared To Previous Generations, The 9500-16i Adapter Delivers The Performance And Scalability Needed By Critical Applications.
$890
SAS9500-16I Technical Specifications
Broadcom 16-Port Int 12Gb/s SAS/SATA/PCIE (NVMe) Tri-Mode HBA
Brand Name: Boardcom
Model Number or SKU# SAS9500-16I
Product Type: Controller
Product Name: SAS-SATA
key Features
Port Count 16 Internal
Connectors Two X8 Sff-8654
Host Interface X8 Pcie Gen 4.0
Storage Interface 12gb/s Sas, 6gb/s Sata, Gen 4.0 Pcie (nvme)
Management Utilities
Lsi Storage Authority (lsa)
Storcli (command-line Interface)
Hii (uefi Human Interface Infrastructure)
Os Support Microsoft Windows, Vmware Vsphere/esxi, Red Hat Enterprise Linux, Suse Linux, Ubuntu Linux, Citrix Xenserver, Centos Linux, Debian Linux, Oracle Enterprise Linux, Fedora, Freebsd.
Dimensions 6.127 In. × 2.712 In. (155.65 Mm × 68.90 Mm)
Operating Conditions
Operating: 0°c To 55°c, 5% To 90% Non-condensing
Storage: -45°c To +105°c, 5% To 95% Non-condensing.
Typical Power 8.9w
Operating Voltage 12v ±8%, 3.3v ±9%
