SCL500RM1UC APC Smart-UPS Li-Ion 500VA Short Depth

SCL500RM1UC Technical Specifications

APC Smart-UPS Li-Ion 500VA Short Depth with SmartConnect UPS 400 W

Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS Li-Ion
Model :500VA Short Depth with SmartConnect
Packaged Quantity :1
500VA
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232, USB
Interface Provided
Interfaces :1 x management (RS-232) – RJ-45, 1 x management (USB)
Power Device
Form Factor :Rack-mountable
UPS Technology :Line interactive
Voltage Provided :AC 120V
Voltage Provided Margin :± 5%
Frequency Provided :50/60 hertz
Frequency Provided Margin :± 3Hz
UPS Output Waveform :Sinewave
Power Provided :400 watt
Power Capacity (VA) :500 volt ampere per kilogram
Voltage Required :AC 120 volt
Input Voltage Range :AC 92 – 139 V
Frequency Required :50/60 hertz
Frequency Required Margin :± 3Hz
Input Connector Type :Power NEMA 5-15P
Input Connector Qty :1
Output Connector Qty :4
Surge Suppression :Yes
Efficiency :96% at 10% Load
Power Device Features :Audible alarm, LCD display
UPS
Battery Technology :Lithium ion
Miscellaneous
Color :Silver, Black
Color Category :Silver, Black
Height (Rack Units) :1
Compliant Standards :REACH, IP20, UL 1449, CSA C22.2 No. 107.1, RoHS, UL 1778, FCC Part 15 A, NOM
Dimensions & Weight
Width :17 inch
Depth :9.1 inch
Height :1.7 inch
Weight :8.16 lbs
Dimensions & Weight (Shipping)
Shipping Weight :9.26 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
Sound Emission :45 dBA
