SFPP-10G-ER-OTN Juniper SFP+ 10GE Er Pluggable Transceiver

SFPP-10G-ER-OTN Technical Specifications

Juniper Networks SFP+ 10GE Er Pluggable Transceiver

Product Name: SFP+ 10GE Er Pluggable Transceiver Dual
Manufacturer Part Number: SFPP-10G-ER-OTN
Product Type: SFP+
Ethernet Technology: 10 Gigabit Ethernet
Media Type Supported: Optical Fiber
Network Technology: 10GBase-ER
Environmentally Friendly: Yes
Fiber Optic Cable Standard: 9/125 µm
Fiber Mode Supported Single-mode
Expansion Slot Type: No
Interfaces / Ports Details: 1 x LC 10GBase-ER Network
Transmitter output power, each lane (minimum): –4.7 dBm
Transmitter output power, each lane (maximum): 4.0 dBm
Receiver input power, each lane (minimum): –15.8 dBm
Receiver input power, each lane (maximum): –1.0 dBm
Cable type: SMF
Core size/cladding: 9/125 µm
Distance: 40 km
Maximum Power consumption (W): 1.5 W
Operating Temperature (range): –5° C to 85° C
Storage temperature: –40° C to 85° C
