SMX3000RMLV2U APC Smart-UPS X 3000VA Rack/Tower LCD 100-127V

SMX3000RMLV2U Overview

APC award-winning Smart-UPS is the most popular UPS in the world for servers, storage and network power protection. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power. In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today’s multi-core or virtualized servers that have varying load consumption. Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery. The entry level Smart-UPS SC is an economical choice for small and medium businesses looking to protect small switches, networking devices and point-of-sale (POS) equipment.

$2,291

Buy Now
Availability: In Stock
SKU:SMX3000RMLV2U
Brand:

SMX3000RMLV2U Technical Specifications

APC Smart-UPS X 3000VA Rack/Tower LCD 100-127V

Manufacturer :APC
Brand :APC
Product Line :APC Smart-UPS X
Model :3000 Rack/Tower LCD
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :USB, RS-232
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SmartSlot
Interface Provided
Interfaces :1 x EPO (emergency power off), 1 x management
Cable Details
Cables Included :Serial cable, USB cable, Power cable 8 ft
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :Line interactive
Voltage Provided :AC 120 volt
Voltage Provided Margin :± 5%
Frequency Provided :47 – 53 / 57 – 63 hertz
UPS Output Waveform :Sinewave
Power Provided :2.7 kilograms per millimetere
Power Capacity (VA) :3000 volt ampere per kilogram 3000VA
Voltage Required :AC 120 volt
Frequency Required :50/60 hertz
Input Connector Type :Power NEMA L5-30
Input Connector Qty :1
Output Connector Qty :7
Surge Suppression :Yes
Surge Energy Rating :540 joules
Circuit Protection :Circuit breaker
Power Device Features :LED indicators, Audible alarm, LCD display
Power Output Connectors Details
Power Output Connectors Details :3 x power NEMA 5-15, 3 x power NEMA 5-20, 1 x power NEMA L5-30
Battery
Run Time (Up To) :6.3 minute (time unit)
Load Type :At full load
Recharge Time :3 Hours
Run Time Details
Run Time (Up To) :18 min at half load, 6.3 min at full load
UPS
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Rack Mounting Kit :Included
Height (Rack Units) :2
Equipment Protection Value :150000 US Dollars
Compliant Standards :UL 1778, UL 1449, REACH, CSA, NOM, EN55022 Class A, FCC Part 15 A, BSMI, EN 50091-2, RoHS Exemption 7b, VCCI, TUV
Dimensions & Weight
Width :17 inch
Depth :26.3 inch
Height :3.3 inch
Weight :84.88 lbs
Dimensions & Weight (Shipping)
Shipping Width :23.5 inch
Shipping Depth :34.2 inch
Shipping Height :9.6 inch
Shipping Weight :100.09 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Sound Emission :55 dBA
