SX550X-16FT-K9 Cisco 550X Series 16 Ports Managed Switch
SX550X-16FT-K9 Overview
The SX550X-16FT-K9 Cisco 550X Series 16-port managed switch offers a variety of power options and redundancy features to ensure that your network stays up and running even in the event of a power failure:
External Power Supply: The switch is powered by an external power supply, which can be connected to an AC power outlet.
Redundant Power Supply (RPS) Support: The switch supports the use of an RPS, which can provide redundant power in the event of a power failure. This helps to ensure that the switch continues to operate even if the primary power supply fails.
SX550X-16FT-K9 Technical Specifications
Cisco 550X Series 16 Ports Managed Twisted Pair Rack-mountable Supported Stackable Layer 3 Switch – 8 10GBase-T Ports & 8 10-Gigabit Small Form-Factor Pluggable Plus (SFP+) Ports
Manufacturer: Cisco
Part Number: SX550X-16FT-K9
Product Series: 550X
Product Type: Ethernet Switch
Technical Specifications
Device Type: Switch – 16 Ports – L3 – Managed – Stackable
Enclosure Type: Desktop, Rack-mountable
Subtype: 10 Gigabit Ethernet
Ports: 8 x 10GBASE-T + 8 x 10 Gigabit SFP+
Performance
Forwarding Performance (64-byte Packet Size): 238.08 Mpps
Switching Capacity: 320 Gbps
Capacity
VLANs Supported: 4094
IPv4 Routes (Static): 7168
IPv6 Routes (Static): 1792
IPv6 Interfaces: 256
IP Interfaces: 256
MSTP Instances: 16
QoS Hardware Queues: 8
Packet Buffer Size: 3 MB
MAC Address Table Size: 32000 Entries
Jumbo Frame Support: 9000 Bytes
Max Units in a Stack: 8
