TOP-1600WM1 Epower 1600W POWER SUPPLY

TOP-1600WM1 Technical Specifications

Epower 1600W EPS ATX12V MINING POWER SUPPLY

Brand: TOPOWER
Series: MINING
Model: TOP-1600WM1
Type: ATX12V / EPS12V
Maximum Power: 1600W
Fans: Single Fan
PFC: Active
Main Connector: 24+8Pin
+12V Rails: Single
PCI-Express Connector: 16 x 6+2-Pin
SATA Power Connector: 8
SLI: SLI Ready
CrossFire: CrossFire Ready
Modular: Non-Modular
Efficiency: > 85%
Over Voltage Protection: Yes
Overload Protection: Yes
Input Voltage: 100 – 240 V
Input Frequency Range: 50/60 Hz
Max PSU Length: 165 mm
Type: ATX 12V / EPS 12V
Power Rating: 1600W
PFC: Active
+12V Rails: Single
Output:
+3.3V Max. Current: 20A
+5V Max. Current: 20A
+12V1 Max. Current: 128A
-12V Max. Current: 0.5A
+5VSB Max. Current: 3A
Connectors:
Main Connector: 20+4 Pin
12V Power Connector: 1 x 4+4 Pin ATX/EPS 12V
PCI-Express Connector: 16 x 6+2P
SATA Power Connector: 8
Peripheral Connector: 6
