UCS-SPR-C240M5-S4 Cisco Systems SP C240 M5SX 1X4110 1X16GB
UCS-SPR-C240M5-S4 Overview
UCS C240 M5 SFF server extends the capabilities of Cisco’s Unified Computing System portfolio in a 2U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots for 2666 MHz DDR4 DIMMs and up to 128GB capacity points, up to 6 PCI Express (PCIe) 3.0 slots, and up to 26 internal SFF drives. The C240 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card.
$3,689
UCS-SPR-C240M5-S4 Technical Specifications
Cisco Systems SP C240 M5SX 1X4110 1X16GB
General Information
Product Name SP C240 M5SX 1X4110 1X16GB Memory Single Rank
Manufacturer Part Number UCS-SPR-C240M5-S4
Product Series C240 M5
Product Type Server
Controllers
Controller Type 12Gb/s SAS
RAID Supported Yes
RAID Levels 0, 1, 5, 6, 10, 50, 60, JBOD
Display & Graphics
Graphics Controller Manufacturer ASPEED
Graphics Controller Model Pilot 4
Graphics Memory Capacity Up to 16 MB
I/O Expansions
Number of Total Expansion 26 Bays
Number of Internal 2.5″ Bays 26
Hot Swap Bays Yes
Memory
Standard Memory 16 GB
Maximum Memory 3 TB
Memory Technology DDR4 SDRAM
Number of Total Memory Slots 24 DDR4 Slots
Number of Occupied Memory Slots 1
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
Power Description
Input Voltage 120 V AC
230 V AC
Number of Power Supplies Supported 2
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 1100 W
Redundant Power Supply Yes
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 1
Processor Manufacturer Intel
Processor Type Xeon Silver
Processor Model 4110
Processor Core Octa-core (8 Core)
Processor Speed 2.10 GHz
