UCSC-C240-M4S2 Cisco UCS C240 M4 High-Density Rack Server

UCSC-C240-M4S2 Overview

The UCS C240 M4 SFF server is 2-socket, 2U rack server from Cisco, designed for both performance and expandability over a wide range of storage-intensive infrastructure workloads from big data to collaboration. The enterprise-class UCS C240 M4 SFF server extends the capabilities of Cisco’s Unified Computing System portfolio in a 2U form factor. In addition, the UCS C240 M4 SFF server provides 24 DIMM slots, up to 6 PCI Express (PCIe) 3.0 slots, up to 24 front-loading drives plus two (optional) internal SATA boot drives for a total of 26 internal drives.


Buy Now
Availability: In Stock

UCSC-C240-M4S2  Technical Specifications

Cisco UCS C240 M4 High-Density Rack Server

Brand: Cisco
Product Line: Cisco UCS
Model: C240 M4 High-Density Rack Server (Small Form Factor Hard Disk Drive Model)
Manufacturer: Cisco Unified Computing
Available Memory Slots: 24
Data Integrity Check: ECC
Max Memory Supported: 768 GB
Memory Slots: 24
Memory Supported: PC4-17000 – 384 GB registered – ECC
Memory Technology: DDR4 SDRAM
RAM Installed: 0 GB
Network & Communication
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controllers: Intel I350
Ethernet Ports: 2 x Gigabit Ethernet
Installed Size: 8 megabyte
Operating System: No operating system
Manufacturer Form Factor: Rack-mountable
Product Type: Server
Server Storage Bays: Hot-swap
Dimensions & Weight
Height: 3.4 inch
Height (Rack Units): 2
Width: 17.6 inch
Depth: 29.1 inch
