EX2300-24MP Juniper EX2300 8x1GbE/2.5GbE +16x1GbE Switch

EX2300-24MP Overview

The Juniper Networks EX2300 Ethernet Switch offers a compact, high performance solution for supporting today’s converged network access deployments. It includes an ASIC-based Packet Forwarding Engine (PFE) with an integrated CPU to consistently deliver wire-rate forwarding, even with all control plane features enabled.


Buy Now
GTIN: 832938084339
Availability: In Stock

EX2300-24MP Technical Specifications

Juniper EX2300 8x1GbE/2.5GbE + 16x1GbE Ethernet Switch

Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks EX Series
Packaged Quantity :1
Airflow Direction :Side to side airflow
Installed Qty :1
Manufacturer :ARM
Clock Speed :1.25 GHZ
Installed Size :2 GB
Flash Memory
Installed Size :8 GB, 8 GB
Performance :Data transfer rate: 208 Gbps, Backplane speed: 80 Gbps, Throughput: 154 Mbps
Capacity :Host IPv6 routes: 2048, IPv6 route prefixes: 512, ARP entries: 5000, LAG groups: 128, Maximum number of concurrent sessions: 4, IPv4 route prefixes: 512, Maximum member ports per LAG: 8, Firewall ingress filters: 256, Host IPv4 routes: 4096, IPv6 routes (Multicast): 2048, IGMP snooping entries: 2000, QoS hardware queues per port: 8, IPv6 neighbor table entries: 1500, Virtual interfaces (VLANs): 4093, Firewall egress filters: 256, IPv4 routes (Multicast): 4096, Access Control Entries (ACEs) per ACL: 2000, VSTP instances: 253, Layer 3 multicast groups: 2048
Type :Switch
Subcategory :Network hubs and switches
Subtype :Gigabit Ethernet
Form Factor :Desktop, Rack-mountable
Ports Qty :24
Advanced Switching :Layer 3
MAC Address Table Size :16000 entries
