TUF GAMING 550B Technical Specifications
Asus Power Supply 550W ATX 12V 80 Plus Bronze RoHS
Product Name: Asus Power Supply Tuf Gaming 550B 550W ATX 12V 80 Plus Bronze RoHS
Manufacturer Part Number: TUF GAMING 550B
Product Type: Power Supply
Number of +12V Rails: 1
Product Family: TUF Gaming
Specification Compliance: ATX12V/EPS12V
Form Factor:
Internal
ATX
Output Voltage:
3.3 V DC
5 V DC
12 V DC
-12 V DC
Number of Fans: 1
Output Voltage Detail:
3.3 V DC @ 25 A
5 V DC @ 20 A
12 V DC @ 45.8 A
-12 V DC @ 0.8 A
5 V DC @ 3 A
Height: 5.9″
Width: 5.9″
Depth: 0.3″
Output Current:
25 A
20 A
45.80 A
800 mA
3 A
Product Line: TUF Gaming
