ST1000VN002 Technical Specifications
Seagate 1TB IRONWOLF SATA 5900 RPM 64MB
Seagate IronWolf NAS
Standard Model Number ST1000VN002
Capacity 1TB / 1000GBB
Interface SATA 6GB/s
FEATURES AND PERFORMANCE
Number of Drive Bays Supported 1 to 8
Multi User Technolgy (TB/yr) 180
Rotational Vibration (RV) Sensors No
Dual-Plane Balance Yes
Error Recovery Control Yes
Maximum Sustained Data Transfer Rate OD (MB/s 180
Spindle Speed 5900
Cache (MB) 64
RELIABILTY / DATA INTEGRITY
Load / Unload Cycles 600,000
Nonrecoverable Read Errors per Bits Read, Max 1 per 10E14
Power-On Hours (per year) 8760
Workload Rate Limit (WRL) (TB/year) 180
Mean Time Between Failures (MTBF) (hours) 1M
POWER MANAGEMENT
Startup Current, Typical (12V, A) 1.2
Average Operating Power (W) 3.6
Idle Averag (W) 2.5
Standby Mode / Sleep Mode, Typical (W) 0.8 / 0.8
Voltage Tolerance (5V) ±5%
Voltage Tolerance (12V) ±10%
ENVIRONMENTAL
Temperature (°C)(
Operating (ambient, min) 5
Operatin (drive case, max) 70
Nonoperating (ambient, min) -40
Nonoperating (ambient, max) 70
Halogen Free Yes
Shock, Operating / Nonoperating: 2ms (max, Gs) 80 / 300
Acoustics
Idle (typical, bels) 2.1
Operating (typical, bels)) 2.3
